Main Specifications:
|
Description |
Unit |
Parameter value |
||
|
Rated load |
kg |
750 |
||
|
Tipping load |
kg |
1500 |
||
|
Operating weight |
kg |
3140 |
||
|
Maximum breakout force |
kN |
18 |
||
|
Engine |
Manufacturer |
Xinchai |
||
|
Model |
4D27G31 |
|||
|
Rated power |
Hp/kw |
49.3/36.8 |
||
|
Rated speed |
rpm |
2500 |
||
|
Cooling mode |
Water-cooling |
|||
|
Performance parameter |
Operation mode |
Mechanical & multi-function electronic control |
||
|
Tire standard |
10-16.5 |
|||
|
Maximum speed |
Km/h |
14 |
||
|
Hydraulic system |
Hydraulic flow rate |
L/min |
62.5 |
|
|
Optional large flow |
— |
|||
|
Hydraulic pressure |
bar |
200 |
||
|
Maximum operating height |
mm |
3878 |
||
|
Bucket hinge pin height |
mm |
3057 |
||
|
Cabin top height |
mm |
1960 |
||
|
Maximum horizontal height of bucket bottom |
mm |
2851 |
||
|
Length without bucket |
mm |
2533 |
||
|
Length with bucket |
mm |
3310 |
||
|
Toppling angle |
° |
40 |
||
|
Maximum unloading height |
mm |
2375 |
||
|
Ground-bucket angle |
° |
30 |
||
|
Rotating angle of bucket at highest point |
° |
83 |
||
|
Unloading distance |
mm |
575 |
||
|
Wheel base |
mm |
1027 |
||
|
Departure angle |
° |
25 |
||
|
Ground clearance |
mm |
183 |
||
|
Front radius of turning circle (without bucket ) |
mm |
1183 |
||
|
Front radius of turning circle (with bucket) |
mm |
2066 |
||
|
Rear radius of turning circle |
mm |
1564 |
||
|
Length of tail |
mm |
1005 |
||
|
Wheel track |
mm |
1380 |
||
|
Tire edge width |
mm |
1640 |
||
|
Bucket edge width |
mm |
1800 |
||
|
Bucket capacity (stacking height) |
m³ |
0.45 |
||
|
Bucket capacity (tiling) |
m³ |
0.35 |
||
|
Diesel tank capacity |
L |
80 |
||
|
Capacity of hydraulic oil tank |
L |
60 |
||
