Description |
|
Unit |
Parameter value |
|||
|
Wheel base |
|
mm |
4500 |
|||
|
Tread |
|
mm |
2710 |
|||
|
Dump clearance at maximum lift |
|
mm |
3845 |
|||
|
Reach at maximum lift |
|
mm |
2168 |
|||
|
Minmum ground clearance |
|
mm |
505 |
|||
|
Overall machine dimension L×W×H |
|
mm |
12337×3875×4319 |
|||
|
Rated operating load |
|
kg |
12000 |
|||
|
Bucket capacity |
|
m³ |
6.5 |
|||
|
Machine weight |
|
kg |
50000 |
|||
|
Max.breakout force |
|
kN |
394 |
|||
|
Total cycle time |
|
s |
15.3 |
|||
|
Minimum turning radius (at tire center) |
|
mm |
7622 |
|||
|
Articulation angle |
|
° |
40 |
|||
|
Gradeability |
|
° |
25 |
|||
|
Tyre size |
Radial35/65R33 |
|||||
|
EngineModel |
CummnisQSK19 |
|||||
|
Rated Power/Speed |
|
kW/rpm |
418/2000 |
|||
|
Travel Speed |
|
Ⅰ-gear(F/R) |
km/h |
6.5/6.5 |
||
|
|
Ⅱ-gear(F/R) |
km/h |
12/12 |
|||
|
|
Ⅲ-gear(F/R) |
km/h |
20/20 |
|||
|
|
Ⅳ-gear(F) |
km/h |
33/33 |
|||
We are a professional construction machinery exporter, specialized in supplying international market with kinds of top brand Chinese construction machinery and its spare parts.
Fill out the form now to receive a custom quote for your project or business. You’ll get a reply within 24 hours!
